Brand:Tektronix
Model:TDS5A38
Frequency Bandwidth:Up to 1 GHz
Sample Rate:Up to 5 GS/s
Channels:4 Channels
Vertical Resolution:8-bit
Memory Depth:Up to 20 Mpts per channel
Waveform Capture Rate:Up to 200,000 wfm/s
Display:10.4-inch XGA TFT LCD
Interface:USB, LAN, GPIB, HDMI
Software Support:Included with P6316 Logic Probes and TekVPI Probes
The Tektronix Oscilloscope TDS5A38 is designed to provide unparalleled performance and flexibility in signal analysis. With a frequency bandwidth of up to 1 GHz and a sample rate of up to 5 GS/s, it delivers precise measurements essential for today’s demanding applications. The 4-channel configuration allows for comprehensive signal comparison and analysis. Its 8-bit vertical resolution ensures high accuracy, while the generous memory depth of up to 20 Mpts per channel supports complex waveform capture. The oscilloscope’s high waveform capture rate of up to 200,000 wfm/s enables quick identification of transient events and anomalies. The large 10.4-inch XGA TFT LCD display provides clear visualization of waveforms, making it easier to interpret data. Additionally, the oscilloscope includes a variety of interfaces including USB, LAN, GPIB, and HDMI, facilitating easy integration with other devices and systems. The included P6316 Logic Probes and TekVPI Probes further enhance its functionality and versatility.
