Net Weight (kg):0.339
Packaging Dimensions:14.90 x 15.30 x 4.30 cm
Model Type:SIMATIC S7-1500
Model Number:6ES7522-1BL01-0AB0
Manufacturer(s):SIEMENS
Category:Programmable Logic Controller (PLC)
Designation:Other
Channel Count:32
Channel Configuration:Groups of 8
Current Per Group:4 A
Power Supply Voltage:24V DC
Current Rating:0.5 A
Switching Mode:Source output (PNP, P-switching)
Diagnostic Features:Short-circuit to L+, Ground wire break, Supply voltage specification
Lifecycle Status:Active
Weight in lb:0.077
Product Group:4520
Group Code:R111
The Siemens 6ES7522-1BH00-0AB0 Digital Output Module is specifically designed for applications requiring precise and reliable control within the industrial automation sector. This module offers an advanced solution for managing outputs with high efficiency and minimal power consumption, ensuring optimal performance in various industrial environments.
With its robust design and compact size, this module seamlessly integrates into existing automation systems, enhancing their capabilities without compromising on space. The 32-channel configuration allows for flexible and scalable integration, catering to diverse control needs across different industries.
Featuring single-channel diagnostics, the module provides real-time monitoring and alerts for potential issues, enabling proactive maintenance and minimizing downtime. This feature ensures continuous operation and improved system reliability, which is critical for maintaining high productivity levels in manufacturing processes.
Equipped with a standard power supply voltage of 24V DC and load voltage of 24V DC, the module is compatible with a wide range of devices, offering seamless integration and compatibility. The high current capacity of 0.5A per channel ensures that it can handle demanding loads without overheating or compromising on performance.
The color-coded CC02 and the option for front connectors using screw terminals or push-in mechanisms facilitate easy installation and maintenance, saving valuable time and reducing errors during setup. The module’s compatibility with SIMATIC S7-1500 series also ensures seamless integration with other Siemens automation components, providing a cohesive and efficient automation ecosystem.
