Reliance 10V4160 GV3000 3-Phase 10HP AC Drive

In stock

The Reliance 10V4160 is a high-performance 10HP AC drive controller from the GV3000 series, designed for versatile industrial applications. It provides reliable speed control for motors and can switch between V/Hz and vector regulation, ensuring efficient operation in demanding environments.

Manufacturer:Reliance Electric

Series:GV3000

Part Number:10V4160

HP:10 HP

Input Voltage:380-460 VAC

Enclosure Type:NEMA 1 / IP20

Keypad/Display:Built-In Keypad

Phase:3 Phase

kW:7.5kW

Frequency:50/60Hz

Controller Capacity:13.4 KVA

Maximum Amperage Input:16.8A

Maximum Amperage Output:14.2A

Full Load Power Loss:250 watts

The Reliance Electric 10V4160 GV3000 AC Drive provides superior performance with the ability to switch seamlessly between standard V/Hz regulation and vector regulation, ensuring precise motor control for a wide range of industrial applications.

With a robust 10 HP rating and a versatile input voltage range of 380-460 VAC, this drive is designed to meet the demanding needs of industrial environments.

The NEMA 1/IP20 enclosure ensures protection against dust and light splashes, making it suitable for indoor installations in harsh conditions.

Equipped with a built-in keypad and display, users can easily monitor and adjust settings, enhancing operational efficiency.

This model boasts a 14.2A output current capability under standard regulation and can deliver a 1-minute burst of 150% output current when switched to vector regulation, providing enhanced performance for heavy-duty tasks.
