Type:CP1H
Product ID:CP1H-XA40DT1-D
Input/Output:24 IN / 16 OUT
Power Supply:24 VDC
Pulse Output Axes:4 axes
High-Speed Counters:Differential phase for 4 axes
Interrupt Inputs:8 built-in
Communication Ports:2 Serial (RS-232C or RS-485)
Weight:Approximately 0.5 kg
Dimensions:137 x 90 x 75 mm (L x W x H)
The OMRON CP1H-XA40DT1-D Chassis Mount Module is an advanced control logic unit designed for industrial automation needs. It supports pulse output for four axes, ensuring high-precision positioning control. Additionally, it features high-speed counters capable of differential phase handling for four axes, which simplifies multi-axis control within a single unit. With eight interrupt inputs included, this module can process instructions at an approximate rate of 500 per second, thereby accelerating the overall system operation.
This module is equipped with serial communications supporting two ports, allowing for the selection of RS-232C or RS-485 communication boards as needed. It is also compatible with Ethernet communications, making it a versatile choice for modern industrial networks. The CP1H-XA40DT1-D is built with robust design principles to withstand the rigors of industrial environments, ensuring long-term reliability and performance.
