Application:Turbo-generator control systems
Type:Emergency Overspeed Board
Series:Mark V
Board Revision:DS200TCEAG1B
Connectors Included:[“J7 PD Core Power Distribution”,”JK TCEB Board Signal”,”JL TCTG Board Trip Signal”,”JW TCEB Board Flame Detection”,”JX1 & JX2 Daisy Chained IONET”]
Technology:Speedtronic
Functionality:Emergency shutdown, overspeed protection, flame detection
Hardware Components:High-quality, industrial-grade components
Compatibility:Direct replacement for DS200TCEAG1 parent board
The GE FANUC DS200TCEAG1B Emergency Overspeed Board is specifically engineered for integration into the Mark V Series of turbine control systems, ensuring seamless operation within industrial settings. This robust board is meticulously designed to handle extreme environmental conditions, boasting an operating temperature range from -40°C to +70°C.
Equipped with advanced communication interfaces, including RS-485 Modbus-RTU, the board facilitates efficient data exchange, enhancing system performance and reliability. It includes 3 Form C relay outputs capable of handling up to 1A at 24VDC, providing critical control signals for turbine operations.
Safety is paramount, and the DS200TCEAG1B excels in this aspect with its superior over-speed protection feature. When an overspeed condition is detected, it immediately triggers a trip signal output to the Electronic Engine Controller (EEC), ensuring rapid and safe shutdown of the turbine system.
Crafted with an aluminum alloy housing reinforced with an epoxy coating, the board offers durability and resistance against corrosion and wear. Its compact size of 175mm x 110mm x 50mm and lightweight design (0.5kg) make it easy to integrate into existing systems without compromising on functionality or performance.
Backed by the expertise of GE FANUC, the DS200TCEAG1B Emergency Overspeed Board is a trusted solution for safeguarding turbine operations. Its compatibility with the Mark V Series and adherence to stringent safety standards make it an indispensable component in the realm of industrial control systems.
