Allen-Bradley 1756-LSC8XIB8I ControlLogix Low Speed Counter

Model Type:ControlLogix

Model Number:1756-LSC8XIB8I

Manufacturer:Allen-Bradley

Counter Type:Low Speed

Input Channels:8

Output Channels:N/A

Sampling Rate:Variable, up to 20 kHz

Resolution:Microseconds

Accuracy:±0.001%

Power Consumption:≤1 W

Operating Temperature:-40°C to +85°C

Storage Temperature:-40°C to +125°C

Communication:Integrated Ethernet

Connector Type:36-pin

Mounting:Panel

Enclosure Rating:IP20

    The 1756-LSC8XIB8I ControlLogix Low Speed Counter is specifically designed for industries that demand precise measurement capabilities in slow-speed applications. Its high-resolution time measurement ensures accurate process control, making it indispensable in sectors such as manufacturing, automation, and process control.

    Featuring 8 analog inputs and 8 digital outputs, this counter provides versatile connectivity options for integrating with various sensors and actuators. It supports EtherNet/IP communication protocol, facilitating seamless data exchange within complex control networks.

    Equipped with a wide operating temperature range (-10°C to 55°C), the 1756-LSC8XIB8I is built to withstand harsh environments commonly found in industrial settings. Its compact size and lightweight design ensure easy installation and maintenance.

    With a counting range of up to 4 billion counts and a resolution of 0.001 seconds, this counter offers unparalleled precision, enabling users to achieve high accuracy in their measurement tasks. This makes it particularly suitable for applications where small changes in speed or timing can significantly impact the overall process efficiency.

    For optimal performance, the 1756-LSC8XIB8I requires a power supply of 10 to 31 VDC, ensuring stable operation under varying electrical conditions. It comes with a comprehensive set of diagnostics tools, providing real-time monitoring of input and communication status, and module health, thus enhancing system reliability and reducing downtime.
